Product Introduction：
Incoloy and Inconel are patented products of American Superalloy Company. They are two different series of steels, both belonging to nickel chromium iron alloy.Incoloy is a heat-resistant nickel chromium iron alloy, and Inconel is a heat-resistant and corrosion-resistant nickel chromium iron alloy. Incoloy and Inconel are both registered trademarks of the International Nickel Co.
Incoloy is applicable to sulfuric acid of various concentrations at low temperature; In caustic soda (such as NaOH) solution with concentration of 50%~70%, it has good corrosion resistance and does not produce stress corrosion cracking. Inconel is applicable to various solutions and acids containing Cl -, as well as caustic soda with concentration less than 70% and many other media.
Incoloy is a nickel chromium iron alloy designed for oxidation resistance and carbonization when temperature rises. There are many types of Incoloy alloys: Incoloy800, Incoloy800H, Incoloy800HT, Incoloy825, Incoloy840, Incoloy901, Incoloy925, Incoloy20, Incoloy330, Incoloy25-6Mo, etc. 9 [" r+ |8 X# g9 K+ N1 B
Inconel develops nickel, iron, and cobalt based alloys for applications that typically require excellent mechanical and chemical properties at elevated temperatures. Inconel 718 is a precipitation hardening nickel chromium alloy; The high nickel composition of Inconel 600 makes the alloy have very strong resistance to chloride stress fission corrosion, and can maintain its high corrosion resistance in the reduced state and also have strong corrosion resistance in alkaline solution; Inconel X-750 alloy is mainly composed of γ "Nickel base superalloys with [Ni3 (Al, Ti, Nb)] phase aging strengthening
Chemical Composition
Grade （材质） | C(%) （碳） | Si(%) （硅） | Mn(%) （锰） | P(%) （磷） | S(%) （硫） | Cr(%) （铬） | Ni(%) （镍） | Mo(%) （钼） | Cu(%) （铜） | Al(%) （铝） | Fe(%) （铁） | Ti(%) （钛） |
Incoloy 800 | ≤0.1 | ≤1.0 | ≤1.5 | ≤0.03 | ≤0.015 | 19.0-23.0 | 30.0-35.0 | -- | ≤0.75 | 0.15-0.6 | 37.0-47.0 | 0.15-0.6 |
Incoloy 800H | 0.05-0.1 | ≤1.0 | ≤1.5 | ≤0.03 | ≤0.015 | 19.0-23.0 | 30.0-35.0 | -- | ≤0.75 | 0.15-0.6 | 38.0-47.0 | 0.15-0.6 |
Incoloy 825 | ≤0.05 | ≤0.5 | ≤1.0 | ≤0.03 | ≤0.03 | 19.0-23.5 | 38.0-46.0 | 2.5-3.5 | 1.5-3.0 | ≤0.2 | 22.0-36.0 | 0.6-1.2 |
Incoloy 901 | ≤0.1 | ≤0.6 | ≤1.0 | ≤0.03 | ≤0.03 | 11.0-14.0 | 40.0-45.0 | 5.0-6.5 | ≤0.5 | ≤0.35 | 余量 | 2.8-3.1 |
Incoloy 926 | ≤0.02 | ≤0.5 | ≤2.0 | ≤0.03 | ≤0.01 | 19.0-21.0 | 24.0-26.0 | 60-7.0 | -- | -- | -- | -- |
Inconel 600 | ≤0.15 | ≤0.5 | ≤1.0 | ≤0.03 | ≤0.015 | 14.0-17.0 | 71.0-78.0 | -- | ≤0.5 | -- | 6.0-10.0 | -- |
Inconel 625 | ≤0.1 | ≤0.5 | ≤0.5 | ≤0.015 | ≤0.015 | 20.0-23.0 | 54.0-60.0 | 8.0-10.0 | -- | ≤0.4 | ≤5.0 | ≤0.4 |
Inconel 718 | ≤0.08 | ≤0.015 | ≤0.35 | ≤0.35 | ≤0.015 | 17.0-21.0 | 50.0-255.0 | 2.8-3.3 | ≤0.3 | 0.2-0.8 | 余量 | 0.65-.15 |
Inconel X-750 | ≤0.08 | ≤0.01 | ≤1.0 | ≤0.5 | ≤0.02 | 14.0-17.0 | ≥70 | -- | ≤0.5 | 0.4-1.0 | 5-9 | 2.25-2.75 |
Mechanical property
Grade （材质） | Tensile strength Mpa （抗拉强度） | Yield Strength Mpa （屈服强度） | Elongation (%) （伸长率） | Density (g/cm3) （密度） |
Incoloy 800 | ≥500 | ≥210 | ≥35 | 8.0 |
Incoloy 800H | ≥450 | ≥150 | ≥150 | 8.0 |
Incoloy 825 | ≥550 | ≥220 | ≥30 | 8.1 |
Incoloy 901 | ≥1034 | ≥689 | ≥12 | 8.14 |
Incoloy 926 | ≥650 | ≥295 | ≥35 | 8.1 |
Inconel 600 | ≥550 | ≥240 | ≥30 | 8.4 |
Inconel 625 | ≥760 | ≥345 | ≥30 | 8.4 |
Inconel 718 | ≥965 | ≥550 | ≥30 | 8.2 |
Inconel X-750 | ≥1267 | ≥868 | ≥25 | 8.28 |
Specifications
Technical （工艺） | Thickness （厚度） | Width （宽度） | Finish （表面） | Origin （产地） |
Cold rolled | 0.8mm-3.0mm | Standard: 1219mm 1500mm Special:can be ordered | 2B | TISCO / Outokumpu / Japan / USA etc
|
Hot rolled | 3.0mm-350.0mm | Standard: 1500mm 1800mm 2000mm Special:can be ordered | No.1 | TISCO / Outokumpu / Japan / USA etc
|
Applications
Grade （材质） | Applications （应用） |
Incoloy 800 | 1. Nitric acid condenser - nitric acid corrosion resistance. 2. Steam heating pipe - good mechanical performance. 3. Heating element tube - good mechanical performance. |
Incoloy 800H | 1. Nitric acid condenser - nitric acid corrosion resistance. 2. Steam heating pipe - good mechanical performance. 3. Heating element tube - good mechanical performance. |
Incoloy 825 | Incoloy 825 alloy is widely used in various industrial fields where the service temperature does not exceed 550 ℃. Typical applications are: 1. Heating pipes, containers, baskets and chains used in sulfuric acid pickling plants. 2. Seawater cooling heat exchanger, marine product pipeline system, acid gas environment pipeline. 3. Heat exchangers, evaporators, washing and dipping tubes in phosphoric acid production. 4. Air heat exchanger in petroleum refining 5. Food Engineering 6. Chemical Process 7. Flame retardant alloy for high-pressure oxygen application |
Incoloy 901 | Aeroengine components Turbine disk, compressor disk and journal of gas engine Static structure Turbine outer ring a fastening |
Incoloy 926 | 926 alloy is a versatile material, which can be used in many industrial fields: 1. Fire fighting system, seawater purification system, hydraulic and filling pipeline system in offshore engineering 2. Bleaching tank in cellulose pulp production 3. Polished bars in corrosive oil wells 4. Hose system in offshore engineering 5. Pipelines, joints, air flow systems, etc. in acid gas production 6. Components in flue gas desulfurization system 7. Evaporator, heat exchanger, filter, mixer, etc. in phosphoric acid production 8. Sulfuric acid separation and condensation system 9. Evaporator for concentrating and crystallizing salt 10. Condensation and piping systems in power plants using sewage cooling water 11. Container for corrosive chemicals 12. Production of organic derivatives using acid chloride catalyst 13. Reverse osmosis desalination plant |
Inconel 600 | 1. Thermowells in aggressive atmospheres 2. Vinyl chloride monomer production: resistant to chlorine, hydrogen chloride, oxidation and carbonization 3. Uranium oxidation to hexafluoride: resistant to hydrogen fluoride corrosion 4. Production and application fields of corrosive alkali metals, especially sulfide environment 5. Preparation of titanium dioxide by chlorine 6. Production of organic or inorganic chlorides and fluorides: resistant to chlorine and fluorine corrosion 7. Nuclear reactor 8. Crank neck bottles and parts in heat treatment furnace, especially in carbonization and nitridation atmosphere 9. Alloy 600 is recommended for catalytic regenerators in petrochemical production in applications above 700 ℃ to obtain a long service life. |
Inconel 625 | Low carbon alloy 625 after softening and annealing is widely used in chemical process industry, and its good corrosion resistance and high strength enable it to be used as a thinner structural component. 625 alloy can be used in contact with seawater and bear high mechanical stress. Typical application fields: 1. Components of organic chemical process containing chlorides, especially when acidic chloride catalyst is used 2. Boilers and bleachers for pulp and paper industry 3. Absorber, reheater, flue gas inlet baffle, fan (wet), agitator, deflector and flue in flue gas desulfurization system 4. Used to manufacture equipment and components for sour gas environment 5. Acetic acid and acetic anhydride reaction generator 6. Sulfuric acid condenser |
Inconel 718 | Because of its high temperature strength, excellent corrosion resistance and ease of processing at 700 ℃, 718 can be widely used in various occasions with high requirements. 1. Steam turbine 2. Liquid fuel rocket 3. Low temperature engineering 4. Acidic environment 5. Nuclear Engineering |
Inconel X-750 | The alloy has good corrosion resistance and creep fracture strength at high temperature, good mechanical properties, and is widely used. It has sufficient strength and corrosion resistance and oxidation resistance below 980 ℃. 1. Fabricate springs and bolts working under high temperature; Rotor blades, impellers and other structural parts on gas turbine; 2. Thrust chamber on rocket engine; 3. Thrust reverser on aircraft; 4. Large high pressure vessels; 5. Elastic gas seals, elastic seal modules, rubber mechanical electric heating blades. |
Different Production Standards
Grade （材质） | GB （国标） | ASTM （美标） | DIN （欧标） | JIS （日标） |
Incoloy 800 | NS1101 | N08800 |
W.Nr.1.4876 | NCF800 |
Incoloy 800H | NS1102 | N08810 |
W.Nr.1.4958 | -- |
Incoloy 825 | NS1402 | N08825 |
W.Nr.2.4858 | -- |
Incoloy 901 | GH2901 | -- | W.Nr.2.4662 | -- |
Incoloy 926 | -- | N08926 |
W.Nr.1.4529 | -- |
Inconel 600 | NS3102 | N06600 |
W.Nr.2.4816 | -- |
Inconel 625 | NS3306 | N06625 |
W.Nr.2.4856 | -- |
Inconel 718 | GH4169 | N07718 |
W.Nr.2.4668 | -- |
Inconel X-750 | GH4145 | N07750 |
W.Nr.2.4669 | -- |
Available production type for Incoloy and Inconel
Grade （材质） | Available production type |
Incoloy 800 | Negotiated supply of round steel, bar, strip, pipe, valve seat, ball, flange and forging. |
Incoloy 800H | Negotiated supply of round steel, bar, strip, pipe, valve seat, ball, flange and forging. |
Incoloy 825 | Negotiated supply of round steel, bar, strip, pipe, valve seat, ball, flange and forging. |
Incoloy 901 | Negotiated supply of round steel, bar, strip, pipe, valve seat, ball, flange and forging. |
Incoloy 926 | Negotiated supply of round steel, bar, strip, pipe, valve seat, ball, flange and forging. |
Inconel 600 | Negotiated supply of round steel, bar, strip, pipe, valve seat, ball, flange and forging. |
Inconel 625 | Negotiated supply of round steel, bar, strip, pipe, valve seat, ball, flange and forging. |
Inconel 718 | Negotiated supply of round steel, bar, strip, pipe, valve seat, ball, flange and forging. |
Inconel X-750 | Negotiated supply of round steel, bar, strip, pipe, valve seat, ball, flange and forging. |
