2205 Stainless steel seamless pipe

the product process to determine its performance limitations, generally low precision seamless steel pipe: uneven thickness, the appearance of low brightness tube length into this is high, and the inner surface pitting and black spots difficult to remove; detection and plastic must be processed offline. Therefore, it shows its superiority in high pressure, high strength and mechanical structure.

Standard size for stainless seamless steel pipe

Classification for stainless seamless steel tubes

According to rolling technical

1)Hot rolling and hot extrusion: 304 304L 309S 310S 316L etc.

2)Cold rolled: 304 316L etc.

According to the Different metallographic structure

1)Semi ferrite,Semi Markov system: 436 439 430 444 445 etc.

2)Martensite,austenite,Austenitic - iron ferrite: 304 304L 309S 310S 2205 etc.

Standards for Specifications and appearance quality

A：GB14975-2002/ASTM A240

Hot rolling length:1.5m-10.0mm. hot extrusion length:≥1m.  Cold rolling: wall thickness0.7mm-1.0mm,lenght1.0m-7.0m.

Wall thickenss≥1.0mm,the lenght must be 1.5m-8.0mm.

B: Production technical

Hot rolling technical: Outsise meter - 54.0mm-480mm.  Wall thickness - 4.5mm-45mm.

Cold rolled technical: Outside meter - 6.0mm-200mm.   Wall thickness - 0.5mm-21mm.

C: Standards for wall thickness

Both inside and outside the pipe surface shall not have cracks, folding, cracking, crack, rolling reduction, separation and scarring

and defects, these defects should be completely removed (except for machining tube), after the removal of the outer wall thickness and shall not exceed the negative deviation. Where no more than the allowable negative deviation of the other minor surface defects can not be cleared.

D:Straight channel depth. Hot rolled, hot extruded steel pipe, the diameter is less than or equal to 140mm less than 5% of the nominal wall thickness, the maximum depth of not more than 0.5mm; cold drawing (rolling) steel is not greater than 4% of the nominal wall thickness, the maximum depth of not more than 0.3mm.

E:Both ends of the steel pipe should be cut into a right angle, and remove the burr.

Production process of stainless seamless steel pipe

Production for Hot rolling technical

1)Prepare Round billet.

2)Heating raw materia

3)With the punch for punch

4)Three roll skew rolling, continuous rolling or extrusion.

5)Off set size

6)cooling the tube

7)Pipe Straightening

8)Hydrostatic test

9)Marking,storage

Production for cold rolling technical

1)Prepare Round billet.

2)Heating raw material

3)With the punch for punch

4)Processing pipe head

5)Annealing for pipe

6)Pickling for pipe to into

the bright finish.

7)Oil (copper) for pipe

8)Multi pass rolling

9)Then into Blank tube

10)Heat treatment

11)Pipe Straightening

12)Marking,storage

All kinds of production standards for stainless seamless steel pipe

We can offer 201 202 301 304 304L 309S 310S 36L  321 etc material for stainelss seamless pipe with follwos standard

GB2270-80:Usually for common stainelss seamless pipe standard.

GB/T14976-94: Stainless seamless steel pipe for fluid delivery.

GB/T14975-94: Stainless steel seamless steel pipe for structu.

GB13296-91:Stainless steel seamless steel tubes for boilers and heat exchangers

(GJB2608-96)(YB676-73):Aerospace structure steel thick wall seamless steel pipe/

(GJB2296-95)(YB678-71): Stainless seamless steel pipe for aviation.

GB3089-92: Stainless acid resistant and extremely thin wall seamless steel pipe.

GB9948-88:Seamless steel pipe for petroleum cracking.

(YB/T679-97)(YB679-71):Aerospace 18A hollow rivet thin wall seamless steel

Pipe.

(GJB2609-96)(YB680-71): Thin wall seamless steel pipe for aviation structure.

(YB/T681-97)(YB681-71):20A thin wall seamless steel pipe for aviation use.

GB3090-82:　Stainless steel small diameter steel pipe．

GB5310-95: Seamless steel tube for high pressure boiler.

GB3087-82: Low and medium pressure seamless steel pipe.

ASTM A213:Ferrite and austenitic alloy steel seamless steel tubes for boilers and heat exchangers.

ASTM A269:General purpose austenitic stainless steel seamless steel pipe and welded steel pipe.

ASTM A312 :　Austenitic stainless steel seamless steel pipe welded steel pipe．

ASTM A450：General requirements for carbon, Ferritic and austenitic alloy steel.

ASTM A530：General requirements for Ferritic and alloy steels

for specialized purposes．

ASTM A789：Austenitic stainless steel seamless steel pipe and welded steel pipe．

JIS G3456-88：Stainless steel tube for mechanical structure．

JIS G3448-88：Stainless steel tubes for ordinary pipes．

JIS G3459-88：Pipe with stainless steel pipe．

JIS G3463-88：Stainless steel tube for boiler and heat exchanger．

Q/HYAD：Seamless steel pipe for chemical industry．

Theoretical weight for cold rolling stainelss seamless steel pipe (KG/M)

Small tips for stainless seamless steel pipe

Application

Seamless with wide usage in oue daily life.Such as Drinking water system, hot water system and the safety and sanitation in the first water supply system, building water supply pipe etc filed.

More widely used in aviation field, boiler manufacturing tube, heat exchanger, petroleum, chemical industry, industrial pipe, machinery.

Calculating formula for weight(KG/M)

｛(Outside meter-wall thickness)×wall thickness｝×0.02466=KG/M

Chemical composition
